Individual end point travel adjustment for each side of neutral
Travel adjustment up to 200% of normal travel.
Adjustable neutral position.
Forward or reversed servo travel.
Travel speed can be selected to take up to 8 seconds for 90° travel
Plug your servo into the flying lead on the Digital End Point Adjuster. Plug the other digital End Point Adjuster lead into the selected channel on the receiver. The servo will operate with full travel. The Digital End Point Adjuster has two input keys, the “+” key and the “-“ key. They are used in combination to make adjustments.
With the receiver switched off, press and hold the “-“ key and then switch on the receiver. Release the key and the Digital End Point Adjuster will operate in the reverse direction. To revert to the normal travel direction, perform the above procedure with the “+” key pressed.
Please note that, depending on the accuracy of your transmitter neutral, the servo neutral may shift between forward and reverse. This is not a fault and performing the Neutral Set-up procedure below will reset the neutral.
With the receiver switched off, press and hold both keys and then switch on the receiver. Release the keys and the LED will remain on. Then press and hold the “+” each flash of the L.E.D represent a slower speed, 1 flash is full speed, 2,3,4 or 5 flashes give 90° travel times of 2,3,4 and 8 seconds respectively. .
Note that the neutral position affects the end point positions so it is advisable to set the neutral before setting the end points.
With the stick at neutral, use the “+” or “-“ keys to move the servo neutral to the required position. The servo will move in one direction when the “+” key us pressed and in the other direction when the “-“ key is pressed. The neutral can be adjusted over a range of about 20% of travel.
To enter the end point set-up, press both keys simultaneously for about 1 second. The LED will light to indicate that the end point set-up procedure is active. Release the keys.
Move the transmitter stick to its full movement on one side of neutral. While holding it there, press the “-“ key. The servo travel end point will reduce. Pressing the “+” key will cause the travel to increase. Use the “+” and “-“ keys to move the servo to the required end point position. Repeat this procedure with the transmitter stick to its full travel on the other side of neutral. Move the transmitter stick from side to side to confirm the correct end point positions.
When you are satisfied that the correct settings have been achieved, press and release both keys simultaneously to exit the set-up. The LED will extinguish to confirm that the operational mode is selected. THE NEW SETTINGS WILL NOT BE STORED UNLESS THE SET-UP IS EXITED.
Please ensure that the selection keys cannot be pressed accidentally while
